SVS-1 Junction Box and Surge Protection
Sensing and Systems Integration Solutions
The SmarTek Systems SVS-1 camera junction box (SVS-JB) and the cabinet surge protection card provide protection for signal, control, and power lines. Both solid state chips (for fast transients) and gas tubes (for large transients) are incorporated. The video signal line uses standard BNC connectors while the power and motorized lens control lines us pluggable terminal block connectors.
Features and Specifications
- Video Signal BNC Connectors
- Power and Control Lines use a Pluggable Terminal Block Connector
- Gas Tube and Solid State Surge Protection
- Junction Box mounts using stainless steel bands
- Junction Box includes short pigtail with connector to mate with the camera used
- Junction Box is made of cast aluminum
SVS-1 Junction Box
SVS-1 Cabinet Surge Protector Card
